When training AI models, especially in fields like computer vision, one of the most time-consuming tasks is dataset preparation. Whether you’re building models for image classification, object detection, or any other task, labeling images is often necessary to ensure the model can recognize patterns accurately. Labeling large datasets manually can become quite cumbersome, and that’s where the Image Labeling Desktop Application, built using Python and the Tkinter package, comes into play.

In this article, we will explore how this tool simplifies the image labeling process, making it more accessible for developers and data scientists alike. The tool is open-source and available on GitHub, making it a valuable resource for anyone working on AI models requiring labeled image datasets.

Introduction

The Image Labeling Desktop Application is designed to help users label large image datasets more efficiently. Built using Tkinter, Python’s standard GUI library, this app provides a straightforward graphical interface to assign labels to images and rename files based on those labels.

Whether you’re developing an AI model for recognizing faces, detecting objects, or classifying products, you’ll likely need to manually label your data. The process usually involves opening image files, viewing them, and then categorizing or labeling them, which can take a significant amount of time. With this app, you can streamline that process.

The app allows users to view an image, select a label from a predefined list, and automatically rename the image file to reflect the label—all from a clean and simple interface. The project can be easily customized to fit specific workflows or datasets.

Why Image Labeling Matters

In machine learning, particularly in supervised learning, the performance of your model is only as good as the quality of your labeled data. This makes the labeling process a critical part of developing a high-performance model. Poorly labeled data can introduce noise, which leads to incorrect predictions or misclassifications, reducing your model's accuracy.

In fields like medical imaging, autonomous driving, or product recognition, well-labeled datasets are a must. Therefore, tools that can assist in labeling and organizing large datasets are invaluable to any AI developer.

Key Features of the Image Labeling App

The image labeling desktop application offers several features that make it an essential tool for AI practitioners:

1. User-Friendly Interface: Built with Tkinter, the interface is clean and simple, making it easy for users to navigate through the image labeling process.
2. Label Selection: Users can predefine a set of labels, such as 'Cat', 'Dog', 'Car', etc., and quickly apply these labels to images.
3. Automatic Renaming: Once labeled, the image file name is automatically updated to reflect the assigned label.
4. Custom Directories: Users can specify directories for both the input images and the labeled outputs, making it easy to manage datasets.
5. Real-Time Feedback: The tool provides immediate feedback by displaying the labeled image and confirming the applied label.
6. Batch Labeling: You can label multiple images in sequence without having to manually organize the files afterward.

Setting Up the Application

To get started, you will need to clone the GitHub repository and install the necessary dependencies. The app is built using Python 3.x and Tkinter, and optionally, you can use PyInstaller to compile it into a standalone executable.

Step 1: Clone the Repository

You can clone the repository from GitHub by running:

git clone https://github.com/imankarimi/image-labeling.git

Step 2: Install Dependencies

If you don’t have Tkinter installed, you can install it with:

pip install tk

If you plan to compile the application into an executable file for easy distribution, you’ll also need PyInstaller:

pip install pyinstaller

How the App Works

Once you’ve set up the application, running it will open a graphical interface where you can load a directory containing images. You can then cycle through the images, apply labels, and let the app rename the files automatically.

Here’s a breakdown of how the process works:

1. Choose Input Directory: Select the folder containing the images to be labeled.
2. Assign Labels: Use the dropdown menu or a button selection to assign predefined labels to each image.
3. File Renaming: The app renames the image files based on the assigned labels, so they are organized for your model training.
4. Save & Organize: Once labeled, images can be saved into a new directory for later use in model training or evaluation.

GUI Example:

The main GUI window is built using the Tkinter Frame, Label, and Button widgets, which allow users to navigate and interact with the application. Here's a snippet of the core logic:

import tkinter as tk
from tkinter import filedialog
import os

class ImageLabelingApp:
    def __init__(self, root):
        self.root = root
        self.root.title('Image Labeling App')
        self.image_label = tk.Label(root, text="No image loaded")
        self.image_label.pack()

        self.select_folder_button = tk.Button(root, text="Select Folder", command=self.select_folder)
        self.select_folder_button.pack()

        self.label_buttons = []
        for label in ["Cat", "Dog", "Car"]:  # Example labels
            btn = tk.Button(root, text=label, command=lambda l=label: self.apply_label(l))
            self.label_buttons.append(btn)
            btn.pack()

    def select_folder(self):
        folder_selected = filedialog.askdirectory()
        self.load_images_from_folder(folder_selected)

    def load_images_from_folder(self, folder_path):
        self.image_paths = [os.path.join(folder_path, f) for f in os.listdir(folder_path) if f.endswith(".png")]
        self.current_image = 0
        self.show_image(self.image_paths[self.current_image])

    def show_image(self, image_path):
        self.image_label.config(text=image_path)

    def apply_label(self, label):
        current_image_path = self.image_paths[self.current_image]
        new_image_name = f"{label}_{os.path.basename(current_image_path)}"
        new_image_path = os.path.join(os.path.dirname(current_image_path), new_image_name)
        os.rename(current_image_path, new_image_path)
        self.current_image  = 1
        if self.current_image



In this code, images from a selected folder are displayed, and users can assign predefined labels by clicking buttons. The app renames the images by appending the selected label.




  Customizing for Your Project


One of the app's strengths is its flexibility. You can easily customize it for your projects by editing the predefined label list, modifying the GUI layout, or adding new functionalities such as:

• Adding a keyboard shortcut to assign labels faster.
• Allowing multiple labels per image.
• Implementing undo functionality to revert mislabeling.

Future Enhancements

There are a few potential improvements that could be added to the application:

• Integration with Cloud Storage: Allow users to label images directly from cloud services like AWS S3, Google Cloud Storage, etc.
• Advanced Image Preview: Provide zoom-in and zoom-out capabilities for more detailed labeling, especially useful for datasets like medical imaging.
• Data Augmentation Options: Integrate data augmentation methods like rotation, zoom, or flips for use while labeling to increase dataset diversity.

Conclusion

The Image Labeling Desktop Application simplifies and automates the tedious process of manually labeling images, making it a valuable tool for AI model development. By using Tkinter, the app is lightweight, cross-platform, and easily modifiable to suit various use cases.

For more information and to contribute to the project, check out the GitHub repository: Image Labeling App on GitHub.
